20
Amplon RT Series
No.
Display
Meaning
Category
1
7-segment
display
Number
The combination of the
three categories (left-hand
side) presents relevant
information such as input
voltage, output voltage,
output frequency
, load
capacity etc.
2
SET
Setup mode.
Please refer to
6HWXS0RGH
Status
3
IN
Input
4
OUT
Output
5
BA
TT
Battery status
6
LOAD
Load status
7
TEST
T
est
8
AH
Ampere hour
Unit
9
V
V
oltage
10
%
Percentage
11
Hz
Frequency
12
KV
A
kV
A
13
KW
kW
14
MIN
Minute
15
°C
The UPS’s inter-
nal temperature.
23
25
Table of Contents
Default Chapter
3
Table of Contents
3
Chapter 1 : Important Safety Instructions
5
Safety Instructions
5
Standard Compliance
10
Storage
10
Chapter 2 : Introduction
11
General Overview
11
Package Inspection
11
Functions & Features
15
Exterior & Dimensions
16
Operation Panel
17
LED Indicators
18
Multi-Function Buttons
18
LCD Display
21
7-Segment Display
23
16-Segments Display
25
Error Code Information
26
Rear Panel
28
Chapter 3 : Installation
30
Installation Data
30
Rack Mounting Procedures for the UPS and the Delta External Battery Pack (Optional)
31
Tower Mounting Procedures for the UPS and the Delta External Battery Pack (Optional)
33
Chapter 4 : Connections
36
Pre-Connection Warnings
36
Delta External Battery Pack (Optional) Connection
36
Communication Interface Connection
38
Critical Load Connection
38
Utility Power Connection
39
Chapter 5 : Operation Modes
40
Standby Mode
40
On-Line Mode
40
Bypass Mode
40
Battery Mode
40
ECO Mode
41
Frequency Converter Mode
41
Setup Mode
41
Chapter 6 : Operation
45
Start-Up Procedures
45
Shutdown Procedures
45
Cold Start
45
Silence Function
45
Battery Test
46
Alarm
46
De-Rating Power
46
Input Breaker
47
Generator Compatible
47
Chapter 7 : Communication Interfaces
48
Chapter 8 : Internal Battery Replacement
52
Chapter 9 : Optional Accessories
56
Chapter 10 : Maintenance
57
Ups
57
Batteries
57
Fan
58
Chapter 11 : Troubleshooting
59
Appendix 2 : Warranty
65
