Chapter 1 Introduction |DD Series

1-6

1-3 Dimension

VFD002DD21A; VFD002DDDD21AB; VFD002DD21C; VFD002DD21CB; VFD004DD21A;

VFD004DD21AB; VFD004DD21C; VFD004DD21CB; VFD002DD21E; VFD004DD21E;

Unit: mm [inch]

W W1 W2 H H1 H2 H3 H4 D D1 Φ1 Φ2

215.0

[8.46]

204.0

[8.03]

204.0

[8.03]

170.0

[6.69]

138.5

[5.45]

15.0

[0.59]

15.1

[0.59]

15.5

[0.61]

55.0

[2.17]

8.5

[0.34]

5.0

[0.20]

7.0

[0.28]

Dimensions for Motor

ECMD-B9120GMS
