Chapter 4 Parameter Settings|DD Series
4-41

Multi-function Output (MO3)
Factory setting: 0
Settings Control mode
VF VFPG SVC FOCPG FOCPM
0: No function
○ ○ ○ ○ ○
1: AC drive in operation
○ ○ ○ ○ ○
2: Zero speed frequency signal (including STOP)
○ ○ ○ ○ ○
3: AC drive ready
○ ○ ○ ○ ○
4: Low voltage warning(Lv)
○ ○ ○ ○ ○
5: Fault indication
○ ○ ○ ○ ○
6: Overhead warning (Pr.06.09)
○ ○ ○ ○ ○
7: Detection of braking resistor action level
○ ○ ○ ○ ○
8: Warning indication
○ ○ ○ ○ ○
9: Over voltage warning
○ ○ ○ ○ ○
10: OD command
○ ○ ○ ○ ○
11: CD command
○ ○ ○ ○ ○
12: Demo Indication
○ ○ ○ ○ ○
13: Demo complete
○ ○ ○ ○ ○
14: Emergency stop indication
○ ○ ○ ○ ○
15: Force stop indication
○ ○ ○ ○ ○
16: Door open complete (limit) signal output
○ ○ ○ ○ ○
17: Door close complete (limit) signal output
○ ○ ○ ○ ○
18: Door Close Error
○ ○ ○ ○ ○
19: Position Complete Signal
○ ○ ○ ○ ○
20: Position Detection 1(for door close only)
○ ○ ○ ○ ○
21: Position Detection 2(for door close only)
○ ○ ○ ○ ○
22: Position Detection 3(for door close only))
○ ○ ○ ○ ○
23: Position Detection 1(for door open only)
○ ○ ○ ○ ○
24: Position Detection 2(for door open only)
○ ○ ○ ○ ○
25: Position Detection 3(for door open only)
○ ○ ○ ○ ○
26: PG feedback error
○ ○ ○ ○ ○
27: output signal when unable to open the door
28: over torque (OT1)
 These parameters can be used for external terminal output
Summary of Function Settings
Settings Functions Descriptions
0
No function MO has no function.
01
AC drive in operation The drive is ON when it receives voltage or operation command.
2
Zero speed frequency signal
(including STOP)
Zero speed output signals (including STOP).
3
AC drive ready
Active when the drive is ON and no abnormality detected or
abnormality is cleared.
4
Low voltage warning(Lv) Active when the detected input voltage is too low.
5
Fault indication Active when fault occurs.
6
Overhead warning (Pr.06.09)
A
ctive when IGBT or heat sink overheats to prevent OH turn off
the drive. When temperature higher than 85 = ON, lower than ℃
<80 = OFF℃ .
7
Detection of braking resistor
action level
Active when drive begins software braking, this signal can be
used as brake module VFDB action signal or indicator.
8
Warning indication Active when warning is detected.
9
Over voltage warning Active when over-voltage is detected.
