PARTS LIST
DESCRIPTIONSTOCK NUMBERQTY
ITEM
M/S PAR
SET C2
Power unit
SM500-CP-90
SM1500-CP-30
2
1
*
interface m/s gen 2
int mod m/s 2
22
*
m/s strip 1 2 unitsdwg2530
23
v
cover output parallel 1dwg2532
2
4
v
screw M8X30 SG DIN933 10.9/Geomet-500
M8x30SG DIN933
45
nut M8 A2M8 A2 DIN934
4
6
washer M8 A2
M8 A2 DIN125A
47
lock washer A2
M8 A2 DIN127B
4
8
crinkle washer
M8 SZ DIN137B
4
9
v
PT 3.5x30 ro he A2 T10 selftap
3.5x30 A2 T10210
Load cable cable lug M8Not supplied
2
11
patchcable BK 0.5m RJ45
CBL P SFTP 0.5 BK212
v




Tol.: 0.2mm
Delta Elektronika B.V.








MASTER SLAVE
assembly 2 units


A3
24-06-2018
S.Janse
DWG
2
12

5
8 6
7
Master
1
4
10
11
5
9
3
9
7
8
6

