Delta Elektronika SM70-CP-450 User Manual

PARTS LIST
DESCRIPTIONSTOCK NUMBERQTY
ITEM
M/S PAR
SET C5
power unit
SM500-CP-90
SM1500-CP-30
5
1
*
interface m/s gen 2
int mod m/s 2
5
2
*
cover output parallel 1dwg2532
23
v
cover output parallel 2dwg2533
3
4
v
m/s strip 4 5 unitsdwg2535
2
5
v
screw M8X30 SG DIN933 10.9/Geomet-500
M8x30SG DIN93310
6
nut M8 A2M8 A2 DIN93410
7
washer M8 A2
M8 A2 DIN125A
10
8
lock washer A2
M8 A2 DIN127B
109
crinkle washer
M8 SZ DIN137B
1010
v
PT 3.5x30 ro he A2 T10 selftap
3.5x30 A2 T10
511
Load cable cable lug M8Not supplied
212
patchcable BK 0.5m RJ45
CBL P SFTP 0.5 BK
4
13
v
patchcable BK 1m RJ45
CBL P SFTP 1 BK
114
v




Tol.: 0.2mm
Delta Elektronika B.V.








MASTER SLAVE
assembly 5 units


A3
25-06-2019
S.Janse
DWG
2
13
14

7
9
8
12
6
10
6
10
5
1
4
3
Master
11
7
9
8

