Delta-Q IC650 Charger Manual
Charger Fault Codes
Code Solution
F-0-0-1, F-0-0-2
F-0-0-3, F-0-0-4
F-0-0-6
Internal charger fault. Remove AC and battery for minimum 30 seconds and retry charger. If it fails
again, please contact the manufacturer of your vehicle or machine.
Selecting A Charge Prole
Figure 3:
Press the
Select Charge
Prole Button
to advance
through
the charge
proles. Hold
the button for
10 seconds to
conrm your
selection.
Model: IC650-___________________
Serial No.: DQS_____________________
Prole No. Battery Type
1. Disconnect AC input from the charger, or from the wall
outlet. Wait 30 seconds for the input relay to open.
2. While reconnecting AC input, press and hold the Select
Charge Prole Button. Hold the button until Error Indicator
is on and Battery Charging Indicator starts ashing.
3. Press and release the Select Charge Prole Button to
advance through charging proles loaded on the charger.
The selected charging prole will be displayed up to three
times (e.g. “P-0-1-1” for Prole 11).*
*Process will time out and prole will remain unchanged if
there is 15 seconds of inactivity, a prole number is allowed to
display three times, or if AC power is cycled.
4. Once desired charging prole is displayed, press and hold
button for 10 seconds (see Figure 3) to conrm selection
and exit Prole Selection Mode.
5. Press the Select Charge Prole Button to check that the
desired prole is selected.
Use this table to record the charging proles on your
charger.
Figure 1:
Disconnect AC
input from the
charger.
Figure 2:
Reconnect AC
input while
holding the
Select Charge
Prole Button.
