8
M4 Allen Wrench Supplied
From Step 2
Attach (1) Stabilizer Bar (Part K) to the assembly from step 2 using (2) M4x30 mm Metal Pins (Part U),
(2) M6x60 mm Bolts (Part R) and (2) M6x17mm Barrel Nuts (Part V). Gently pull the Left and Right
Front Leg apart. To install the Stabilizer Bar - Be very careful not to scratch the finish. Use the
Flat Head Screwdriver to hold the Barrel Nut in the proper alignment. Tighten with the Allen Wrench.
K
PULL GENTLY
K. Stabilizer Bar x 1
R
R
R
V . M6x17mm Barrel Nut x 2
V
V
V
U
U. M4x30 mm Metal Pin x 2
Step 3
Section 1: Crib Assembly
Parts and tools required to complete step.
R. M6 x 60 mm Bolt x 2
To Next Page
