9
From Step 3
M4 Allen Wrench
Supplied
L. Mattress Support x 1
Attach the Mattress Support (Part L) in all corners using (1) M6x15mm Bolt (Part T) in each corner.
Tighten with the M4 Allen Wrench.
! WARNINGS ON POUCH MUST FACE UP.
L
ALL CORNERS
T
UP
T. M6 x 15 mm Bolt x 4
Step 4
Section 1: Crib Assembly
Parts and tools required to complete step.
WARNING:
!
!
The Warnings printed on the pouch attached to the
mattress support must face up, the springs must face up.
This crib has (3) adjustment positions, use the highest only
for new borns, move the mattress down as the child grows.
Fall Hazard: When child is able to pull to a standing position,
set mattress to lowest position and remove bumper pads,
large toys and other objects that could serve as steps
for climbing out.
To Next Page
