10
To fold stand, step on pedal to release stand lock and lift up on
handles (Figure 18)
Note: BE SURE TO LOCK MAIN WORKTABLE IN PLACE
ON RAILS AND REMOVE TRAYS AND SIDE TABLES
BEFORE FOLDING STAND. Failure to do so could cause
damage to these items when stand is folded.
ASSEMBLY
Figure 18
Once Tile Saw is at the job sight step on Pedal to
release the stand lock and gently pull handles back and
down towards you until Pedal locks the stand in the
upright position.
Stand Assembly Folded with 10 in. Tile Saw
Stand Assembly Folded with 7in. Tile Saw
Note: Tile Saw is not included with stand.
