TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
GENERAL SAFETY RULES
DESCRIPTION SPECIFICATIONS
Height 21.89" (555.89mm) (stand only)
Dimensions (folded for transport) 55.8” l x 27.69” w x 21.89” h (1417.2 mm l x 703.28 mm w x
555.89 mm h)
Dimensions (extended for use) 54.72” l x 27.69” w x 27.98” h (1389.77 mm l x 703.28 mm
w x 710.75 mm h)
Total Width 27.69" (703.28 mm) (stand only)
Note: Refer to tile saw owners manual for tile saw operations and safety notes.
BE SURE to read and understand all instructions in this manual before using this Wet Tile/ Stone Saw with
Stand. Failure to follow all instructions may result in electric shock, re and/or serious personal injury. Some dust
created by using power tools contains chemicals known to the state of California to cause cancer and birth defects or other
reproductive harm.
Safety is a combination of using common sense, staying alert, and knowing how your tile saw works. Be sure to read your tile saw
manual and this manual to understnad how to use your tile saw safely with this stand.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations that
accompany them deserve your careful attention and understanding. The safety warnings DO NOT, by themselves, eliminate any
danger. There are no substitutes for proper accident-prevention measures.
Someone will be seriously injured or killed if the safety information is not followed.
Someone could be seriously injured or killed if the safety information is not followed.
Moderate or major injury could result if the safety information in this manual is not followed.
DAMAGE PREVENTION AND INFORMATION MESSAGES
These inform the user of important information and/or instructions that could lead to equipment or other property damage if they
are not followed. Each message is preceded by the word ”NOTE,” as in the example below:
NOTE: Equipment and/or property damage may result if these instructions are not followed.
PRODUCT SPECIFICATIONS .......................................... 2
GENERAL SAFETY RULES . ............................................. 2
SAFETY SYMBOLS ........................................................ 2
WORK AREA SAFETY . ................................................... 3
PERSONAL SAFETY ...................................................... 3
TOOL SAFETY ............................................................. 3
SERVICE SAFETY .......................................................... 4
SPECIFIC SAFETY INSTRUCTIONS ................................ 4
CALIFORNIA PROPOSITION 65 ..................................... 4
PRODUCT CONTENT ......................................................5
ASSEMBLY.......................................................................6
VERTICAL SUPPORT LEG ASSEMBLY..............................6
PEDAL ASSEMBLY ..........................................................7
ASSEMBLE PEDAL ASSEMBLY TO MAIN FRAME
ASSEMBLY......................................................................7
ASSEMBLE SUPPORT LEG ROD ASSEMBLY TO
PEDAL ASSEMBLY..........................................................8
ASEMBLE UPPER END OF SUPPORT LEG ROD
ASSEMBLY TO MAIN FRAME ASSEMBLY........................8
ATTACH HANDLE TO STAND ..........................................8
TILE SAW INSTALLATION TO STAND .............................. 9
FRANÇAIS.....................................................................13
ESPAÑOL.......................................................................25
