AS Series Module Manual
6- 12
CR# Name Description Atr. Defaults
201 Instruction set
16#0101: record the peak value again for
channel 1
16#0102: record the peak value again for
channel 2
16#0104: record the peak value again for
channel 3
16#0108: record the peak value again for
channel 4
16#110: record the peak values again for
channels 5
16#120: record the peak values again for
channels 6
16#013: record the peak values again for
channels 1-6
16#0201: enable recording for channel 1
16#0202: enable recording for channel 2
16#0204: enable recording for channel 3
16#0208: enable recording for channel 4
16#0210: enable recording for channels 5
16#0220: enable recording for channels 6
16#023F: enable recording for channels 1-6
16#0301: disable recording for channel 1
16#0302: disable recording for channel 2
16#0304: disable recording for channel 3
16#0308: disable recording for channel 4
16#0310: disable recording for channel 5
16#0320: disable recording for channel 6
16#033F: disable recording for channel1-6
16#0501: restore default settings, clear
setting values in the Flash
16#0502: restore default settings, do not
clear setting values in the Flash
W
0
