1.2.2 EMS Standards
1.2.2.1 EMI
Port Frequency Range Level (Normative) Reference Standard
Enclosure port
(radiated)
(measured at a
distance of 10
meters)
30-230 MHz 40 dB (μV/m) quasi-peak
IEC 61000-6-4
230-1000 MHz 47 dB (μV/m) quasi-peak
AC power port
(conducted)
0.15-0.5 MHz
79 dB (μV) quasi-peak
66 dB (μV) average
0.5-30 MHz
73 dB (μV) quasi-peak
60 dB (μV) average
1.2.2.2 EMS
Environmental
Phenomenon
Reference Standard Test Test Level
Electrostatic
Discharge
IEC 61000-4-2
Contact ±4 kV
Air ±8 kV
Radio Frequency
Electromagnetic Field
Amplitude
Modulated
IEC 61000-4-3
80% AM,
1 kHz
sinusoidal
2.0-2.7 GHz 1 V/m
1.4-2.0 GHz 3 V/m
80-1000 MHz 10 V/m
Power Frequency
Magnetic Field
IEC 61000-4-8
60 Hz 30 A/m
50 Hz 30 A/m
