7.2.5 AS08TC Control Registers
*If you use HWCONFIG to set values in CRs, once the set value is downloaded, the values can be retained in
the module; however if you use TO instruction to write data into CRs, the values CANNOT be retained, after
power failure or after transition of the CPU from STOP to RUN.
Note: The attribute of the CR must be W (write) to use TO instruction.
CR# Name Description
Atr. Defaults
0
Format Setup
0: integer format
1: floating point format
R 0
1
Channel 1 mode setup
0: closed
1: -100 mV to +100 mV
2: J-Type
3: K-Type
4: R-Type
5: S-Type
6: T-Type
7: E-Type
8: N-Type
9: B-Type
R/W
1
2
Channel 2 mode setup
R/W
3
Channel 3 mode setup
R/W
4
Channel 4 mode setup
R/W
5
Channel 5 mode setup
R/W
6
Channel 6 mode setup
R/W
7
Channel 7 mode setup
R/W
8
Channel 8 mode setup
R/W
9
Channel 1 offset
Range: -32768 to +32767
R/W
0
10
Channel 2 offset
11
Channel 3 offset
12
Channel 4 offset
13
Channel 5 offset
14
Channel 6 offset
15
Channel 7 offset
16
Channel 8 offset
17
Channel 1 gain
Range: -32768 to +32767
R/W
1000
18
Channel 2 gain
19
Channel 3 gain
20
Channel 4 gain
21
Channel 5 gain
22
Channel 6 gain
23
Channel 7 gain
24
Channel 8 gain
