AS Series Module Manual
7- 12
CR# Name Description
Atr. Defaults
bit4: channel 5
bit5: channel 6
bit6: channel 7
bit7: channel 8
0: warning
1: alarm
bit8: error in the power supply
bit9: error in the module hardware
bit10: error in calibration
bit11: error in CJC temperature
201
Instruction set
16#0101: record the peak value again for
channel 1
16#0102: record the peak value again for
channel 2
16#0104: record the peak value again for
channel 3
16#0108: record the peak value again for
channel 4
16#0110: record the peak value again for
channel 5
16#0120: record the peak value again for
channel 6
16#0140: record the peak value again for
channel 7
16#0180: record the peak value again for
channel 8
16#01FF: record the peak value again for
channels 1-8
16#0201: enable recording for channel 1
16#0202: enable recording for channel 2
16#0204: enable recording for channel 3
16#0208: enable recording for channel 4
W 0
