Delta AS02HC-A

Chapter 11 DeviceNet Master Scanner Module AS01DNET-A
11-43
1
1
5. Click Network >> Online to scan the connected slave.
6. Click Project List>>Properties as below. Then the Properties dialog box appears. Select Master mode and
then click OK.
