Delta AS02HC-A

AS Series Module Manual
3- 14
_3
CR# Name Description
Atr.
Defaults
46
for channel 2
convenient if the system can convert digital
values to floating-
point values for earier
understanding. Here you can set the minimum
and maximum scale ranges of corresponding
floating-point values for channels.
For example, if the scale range for an analog
to digital input channel is ±10.0 V, it indicates
the maximum value is +10.0 V and the
minimum value is -10.0 V.
If the scale range for an analog to digital input
channel is 4 mA ~ 20 mA. It indicates the
maximum value is 20 mA and the minimum
value is 4 mA.
Note: You can use PLC instruction DSCLP
(API0217
) and set SM685 to ON to use
floating-point operations when a conversion
range needs to edit.
47 The minimum scale range
for channel 3
48
49 The minimum scale range
for channel 4
50
51
The minimum scale range
for channel 5
52
53
The minimum scale range
for channel 6
54
55
The minimum scale range
for channel 7
56
57
The minimum scale range
for channel 8
58
59
The maximum scale range
for channel 1
R
10.0
60
61
The maximum scale range
for channel 2
62
63
The maximum scale range
for channel 3
64
65
The maximum scale range
for channel 4
66
67
The maximum scale range
for channel 5
68
69
The maximum scale range
for channel 6
70
71
The maximum scale range
for channel 7
72
73
The maximum scale range
for channel 8
74
