Delta AS02HC-A User Manual

Chapter 14 High Speed Counter Module AS02HC
14-13
14
Data Format - 12ST:
b9 b8 b7 b6
b11
b10 b3 b2 b1 b0b5 b4
MSB LSB
Sing le-t urn da ta
Data Length (bits): 12
Multi-Turn Data Length (bits): 0
Single-Turn Data Length (bits): 12
Single-Turn Data Start Bit: b11
Status Data Length (bits): 0
Parity Check: No check
Data Format - 13ST:
b9 b8 b7 b6b11 b10 b3 b2 b1 b0b5 b4
MSB LSB
Sing le-t urn data
b12
Data Length (bits): 13
Multi-Turn Data Length (bits): 0
Single-Turn Data Length (bits): 13
Single-Turn Data Start Bit: b12
Status Data Length (bits): 0
Parity Check: No check
Data Format - 12MT+13ST (Default):
b9 b8 b7 b6b11 b10 b3 b2 b1 b0b5 b4
MSB LSB
Single-tur n d ata
b12b22 b21 b20 b19b24 b23 b16 b15 b14 b13b18 b17
Multi-tur n data
Data Length (bits): 25
Multi-Turn Data Length (bits): 12
Multi-Turn Data Start Bit: b24
Single-Turn Data Length (bits): 13
Single-Turn Data Start Bit: b12
Status Data Length (bits): 0
Parity Check: No check
