Chapter 4 Analog Output Module AS04DA
4- 11
4. Refresh time for an Output
Set the refresh time for an output and the system updates the value of the slope (m) accordingly.
Time
Max imum output
Anal og si gnal
Mi ni mum output
When the analog output signal changes, the system updates the value of the analog output according to the
value set in the slope, as shown in the image below.
