AS Series Module Manual
9- 8
9.2.4.2 AS00SCM-A Communication Interface
COM mode: Serial communication extension mode
This module comes with two function card slots, supporting AS-F232, AS-F422, and AS-F485 communication cards.
The Card 2 slot also supports the AS-FCOPM communication card (firmware V2.00 or later). Refer to Chapter 10 for
more information on wiring the cards.
RTU mode: Remote module mode
The Card 2 slot supports the AS-FCOPM communication card (firmware V2.00 or later), AS-FEN02 (firmware V2.02
or later) and AS-FPFN02 (firmware V2.06 or later). Refer to Chapter 10 for more information on wiring the cards.
