Electrical specifications for the outputs
Model
Item
AS02PU-A AS04PU-A
Number of outputs Four (2-axis) Eight (4-axis)
Connector type Removable terminal blocks
Output form differential output Transistor-T (sinking) (NPN)
Output current 5 VDC*
1
5-30 VDC
Maximum
load
Resistance 10 mA 0.1A
Inductance N/A
Bulb N/A
Maximum
output
frequency
*1
Resistance 200 kHz 100 kHz
Inductance N/A
Bulb N/A
Maximum
Response
time
OFF→ON 0.1 μs 1.5 μs
ON→OFF 0.1 μs 1.5 μs
Input isolation 500 VDC
Weight 120 g
*1: Acutal output: 4 VDC (high input impedance) to 3.3 VDC (10 mA)/output
