Chapter 9
E
ther
n
et
Specif
ication and Operation
9
-
53
9_
Select a PLC
and select
the chassis. This exam
ple uses a 1756
-
L71.
Click
Finish
to create the ne
w project.
Select PLC
Select a backplane
260
262
