8
C2
A2 B2
x4
x2
x2
W1
Handle Assembly
Conjunto de asa
E2
x2
D2
P1
Tile
Anchor
Anclaje
de azulejo
x13
O1
Screw
Tornillo
(ST M4 x 40)
x12
Q1
x13
I1
Screw
Tornillo
(ST M4 x 16)
x1
x2
Multi Wrench Tool
Included
Herramienta de llave múltiple
incluida
R1
Acrylic
Anchor
Anclajes de
acrílica
T1
Hex Wrench
Included
Llave Allen
incluidas
(2.5 mm)
HANDLES AND HARDWARE / MANGOS Y HERRAJES
