Delta DVP-EH Series User Manual

Conversion calculation of CH0 DA: Conversion calculation of CH1 DA:
20mA
1,234
0
4,000
?
Analog
output
Digital input
The current is outputted
to ACI of AC drive to be
speed control. If you
need current 12.34mA,
you should give D0:
2468
20
4000
34.12 =×=
mA
mA
0
?
+10V
5.23
4000
Analog
output
Digital input
The voltage is
outputted to AVI of
AC drive to be speed
control. If you need
voltage 5.23V, you
should give D1:
2092
10
4000
23.5 =×=
V
V
