Delta DVP01LC-SL User Manual

- 4 -
CR# Add. Attrib. Register name Explanation
#16 H1010 O R/W
Number of times the
stability of the values
gotten from CH1 is
checked
Default: K5; Range: K1~K500
#18 H1012 O R/W
Range within which the
stability of the values
gotten from CH1 is
checked
Default: K10; Range: K1~K10,000
#20 H1014 O R/W
Number of decimal
places gotten from CH1
Default: K2; Range: K0~K4
#22 H1016 O R/W
Unit of measurement for
weight gotten from CH1
Four ASCII words at most
#23 H1017 O R/W
Unit of measurement for
weight gotten from CH1
#26 H101A X R/W
Weight correction
command
For correcting the weight
Default: H’0000
H’0001: Reset the weight gotten from
CH1 to zero
H’0002: The weight of the weights gotten
from CH1
(Please use CR#41 to make the
correction parameter retentive after
finishing correcting the weight.)
#33 H1021 O R/W
Weight of the weights
gotten from CH1
The default in CR#33 and CR#34 is
K1,000. Range: K-32,768~K32,767
Steps for the correction:
1: Place no weights on the load cell
2: Write H’000 into CR#26.
3: Place standard weights on the load
cell.
4: Write the weight of the weights on the
plate into CR#33.
5: Write H’0002 into CR#26.
#35 H1023 O R
Maximum weight gotten
from CH1
(Low word)
The user can set the maximum weight. If
the weight gotten is larger than the
maximum weight set by the user, the
error code will be recorded.
#36 H1024 O R
Maximum weight gotten
from CH1
(High word)
#37 H1025 O R/W
Upper limit for taking the
weight gotten from CH1
as zero
For judging the zero status
If the weight is within this range, the
status code will be a zero bit, indicating
that there are no weights.
Default: K10
Range: K-32,768 to K32,767
#39 H1027 O R/W
Lower limit for taking the
weight gotten from CH1
as zero
For judging the zero status
If the weight is within this range, the
status code will be a zero bit, indicating
that there is no weight.
Default: K-10
Range: K-32,768 to K32,767
#41 H1029 X R/W
Storing the setting value
(H’5678)
The present setting value is stored. All
setting values are written into the internal
flash memory so that they can be used
next time DVP01LC-SL is turned on.
H0: No action (default)
H’FFFF: The value is stored successfully.
