- 2 -
Electrical Specifications
Model
Item
DVP32ES200RC DVP32ES200TC
Power supply
voltage
100 ~ 240VAC (-15% ~ 10%)
, 50/60Hz ±5%
Connector European standard removable terminal block (Pin pitch: 5mm)
Operation
DVP-ES2 starts to run when the power rises to 95 ~ 100VAC and stops
when the power drops to 70VAC. If the power is suddenly cut off, the
MPU will continue running for 10ms.
Power supply fuse 2A/250VAC
Power consumption 30VA
DC24V current
output*1
500mA
Power supply
protection
DC24V output short circuit protection
Voltage withstand
1,500VAC (Primary-secondary)
, 1,500VAC (Primary-PE),
500VAC (Secondary-PE)
Insulation
resistance
> 5MΩ at 500VDC (between all I/O points and ground)
Noise immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8kV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2kV, Digital I/O: 1kV,
Analog & Communication I/O: 1kV
RS (IEC 61131-2, IEC 61000-4-3): 26MHz ~ 1GHz, 10V/m
Grounding
The diameter of grounding wire shall not be less than that of L, N
terminal of the power supply. (When many PLCs are in use at the same
time, please make sure every PLC is properly grounded.)
Environment
Operation: 0°C~55°C (temperature), 5~95% (humidity), pollution degree
2
Storage: -25°C~70°C (temperature), 5~95% (humidity)
Agency approvals
UL508
European community EMC Directive 89/336/EEC and Low Voltage
Directive 73/23/EEC
Vibration/shock
immunity
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Weight(g) 489 432
*1: It is suggested that the power output should not be supplied to HMIs.
Input Point
Input No. X0 ~ X3 X4 ~ X7 X10 ~ X17
Type Digital input
Input type DC (SINK or SOURCE)
Input current 24VDC, 5mA
Input impedance 3.9kΩ 4.7kΩ
Max. frequency 100kHz 10kHz 60Hz
Off → On >15VDC
Action level
On → Off < 5VDC
Off → On < 2.5μs < 20μs < 10ms
Response time
On → Off < 5μs < 50μs < 15ms
Filter time X0 ~ X7 Adjustable within 0 ~ 20ms in D1020 (Default: 10ms)
Output Point
Output point type Relay-R Transistor-T
Output point number All Y0, Y2 Y1, Y3 Y4~Y17
Voltage specification < 250VAC, 30VDC
5 ~ 30VDC
#1
Max. frequency 1Hz 100kHz 10kHz 1kHz
Resistive 2A/1 point (5A/COM) 0.5A/1 point (4A/ZP)
Inductive
15W (30VDC)
Maximum load
Lamp 20WDC/100WAC 2.5W(30VDC)
Off → On < 2μs < 20μs < 100μs
Response time
On → Off
Approx .10ms
< 3μs < 30μs < 100μs
#1: UP, ZP must work with external auxiliary power supply 24VDC (-15% ~ +20%), rated
consumption approx. 1mA/point.
