Delta E8-TL-US

63
1) Un-balance PV input allowed, maximum input power for each MPP tracker is limited with 70% rating power. And total
input is limited with 100% rating power.
2) The maximum AC power value indicates the power an inverter might be able to deliver, but such a maximum AC
power may not necessarily be achieved.
3) Max. output fault current and duration is 140Apk, 2ms duration@208V, 116.8Apk, 6.15ms duration@240V.
E6-TL-US
E8-TL-US
AC PORT (OFF-GRIG MODE)
Output
Pure sin-wave voltage
Maximum output power
5000 W
Peak output power (30s)
6000 W
AC output voltage
240 Vac
Maximum AC current
21A
Peak AC current(30s)
25A
Frequency range
57Hz to 63Hz
THD @ nominal power
< 5%
Maximum allowed crest factor
2.5 @ 5000 W
RGM (optional)
Integrated comply with ANSI C12.20, Class 0.5
Output terminal
Spring type
GENERAL PV to AC
Isolation level
Transformerless
Type of converter
DC / AC
Peak efficiency
98%
CEC efficiency
97.50%
Operating temperature
-22 °F to 149 °F (-30 °C to 65 °C)
De-rating start temperature
113 °F (45 °C) or above
Humidity
0% to 95%
Maximum operating altitude
9,843 ft (3,000 m) above sea level
Audible noise
< 45 dB(A) @ 3 ft (1 m)
MECHANICAL DESIGN
Dimensions (W x H x D)
16.7 x 23.2 x 5.9 in (425 x 590 x 150 mm)
Weight
45.9 lbs (20.8 kg)
Cooling
Natural convection
Natural convection with
internal fan
Enclosure material
Aluminum alloy
Installation type
Vertical wall mount indoor and outdoor
Warranty
10 years
