Delta M80U User Manual

M80/60U_120
M80/60U_121
Air Outlets /
Smart Fans
Rating Label
DC Switches,
1 per MPPT
DC Switches,
1 per MPPT
Chassis access for DC
wiring; 2" TSO*, 2 places
Chassis access for DC
grounding; ½" TSO*
Air Inlets
Air Outlets /
Smart Fans
Rating Label
Air Inlets
*TSO = Trade Size Opening
RS-485
communications port,
3/4" TSO
RS-485
communications port,
3/4" TSO
RS-485
communications port,
3/4" TSO
LCD/LED Display and
Control Buttons
AC Switch
DC Switch
Bottom: 2" TSO*
Chassis access for DC Wiring;
Side: 2½" TSO*
Chassis access for AC Wiring;
Bottom: 2" TSO*
LCD/LED Display and
Control Buttons
Figure 2-2: Overview of M80/60 series
M80/60U_122
MC4 type DC connector
18 pairs
2½" gland for AC Wiring
½" gland for DC Grounding
LCD / LED Display
and Buttons
AC Switch
AC Switch
Chassis access for AC
Wiring; 2" TSO*
Air Outlets /
Smart Fans
Rating Label
Air Inlets
