Figure 5-17: Disassembling fan tray from PM chassis (showing one side only)

①

②

③

* Screw torque required for assembling: 7 lbf-in (0.8N•m)

* Screw torque required for assembling:

7 lbf-in (0.8N•m)

* Screw torque required for

assembling: 7 lbf-in (0.8N•m)

99

Maintenance
