Delta Performance PG-25

To Next Page

To Previous Page

Replacements Parts

Item Part No. Description

Operating Thermostat

Primary or Secondary

Manual Reset Hight Limit

Pre-set at 205ºF

Auto Reset High Limit

Pre-Set at 194ºF

Temperature / Pressure

Gauge

Control Panel

PGRKIT21

PGRKIT 22

HMCS01

PGRKIT23

HMGAU01

Fig. 41: Control Panel Components
