Delta Performance PG-25

To Next Page

To Previous Page

Replacements Parts

Item Part No. Description

R1 Relay - Controls

Burner Function

R2 Relay - Controls

Domestic Priority & Circulator

120 V-24 V 40VA

Transformer

PGRKIT18

12A

PGRKIT19

12B

PGRKIT 19

12A

12B

24V Circuit

120 V Circuit

Part No. Description

HMRLV01 Pressure Relief Valve 30 psi

P3AVT01 Air Vent

HMVLV07 Thermostatic Mixing valve 3/4"

HNSNP02 Snap sets Male / Female

HMTPV01 Temperature/Pressure Relief Valve (PG-30/35/40/45 only)

HMTPV03 Temperature/Pressure Relief Valve (PG-25 only)

Fig. 42: Electrical Panel Components
