Table 9-4 Fault Message
FAULT
Message
Possible cause
Action
HW DC
Injection
1. Utility waveform is abnormal
2. Detection circuit malfunction
1. Check the utility waveform. Grid connection of
inverter need to be far away from non-linear
load if necessary
2. Check the detection circuit inside the inverter
Temperature
High
1. The ambient is over 60
(The installation is abnormal)
2. Detection circuit malfunction
1. Check the installation ambient and
environment
2. Check the detection circuit inside the inverter
HW NTC1
Fail
1. Ambient temperature >90
or <-30
2. Detection circuit malfunction
1. Check the installation ambient and
environment
2. Check the detection circuit inside the inverter
(RTM1)
Temperature
Low
1. Ambient temperature is
<-30
2. Detection circuit malfunction
1. Check the installation ambient and
environment
2. Check the detection circuit inside the inverter
(RTM1, RTB1, RTG1 and RTH1)
HW NTC2
Fail
1. Ambient temperature >90
or <-30
2. Detection circuit malfunction
1. Check the installation ambient and
environment
2. Check the detection circuit inside the inverter
(RTB1)
HW NTC3
Fail
1. Ambient temperature >90
or <-30
2. Detection circuit malfunction
1. Check the installation ambient and
environment
2. Check the detection circuit inside the inverter
(RTG1)
HW NTC4
Fail
1. Ambient temperature >90
or <-30
2. Detection circuit malfunction
1. Check the installation ambient and
environment
2. Check the detection circuit inside the inverter
(RTH1)
HW DSP
ADC1
1. Insufficient input power
2. Auxiliary power circuitry
malfunction
3. Detection circuit malfunction
1. Check the input voltage, must > 150Vdc
2. Check the auxiliary circuitry inside the inverter
3. Check the detection circuit inside the inverter
HW DSP
ADC2
1. Insufficient input power
2. Auxiliary power circuitry
malfunction
3. Detection circuit malfunction
1. Check the input voltage, must > 150Vdc
2. Check the auxiliary circuitry inside the inverter
3. Check the detection circuit inside the inverter
