Delta SHOPMASTER GR250 - Page 6

6
GRINDER PARTS
Fig. 2
1. Grinder
2. 1/4-20x1/4" hex head screw (2)
3. 5/16-18x5/8" hex head screw (4)
4. Eye shield bolt (2)
5. 5/16-18x3/4" knob (2)
6. Eye shield knob (2)
7. Eye shield spacer (2)
8. 5/16" flat washer (6)
9. 1/4" flat washer (4)
10. Eye shield (2)
11. Left tool rest
12. Left tool rest arm
13. Left spark guard
14. Right spark guard
15. Right tool rest arm
16. Right tool rest
17. Wrench
18. Wheel dresser
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
