Parameter Explanation Settings
Factory
Setting
Customer
Pr.73 Present Fault Record 00
Pr.74
Second Most Recent
Fault Record
00
Pr.75
Third Most Recent
Fault Record
00: No fault occurred
01: Over-current (oc)
02: Over-voltage (ov)
03: Overheat (oH)
04: Overload (oL)
05: Overload 1 (oL1)
06: External Fault (EF)
07: CPU failure 1 (CF1)
08: CPU failure 3 (CF3)
09: Hardware Protection Failure (HPF)
10: Over-current during acceleration (oca)
11: Over-current during deceleration
(ocd)
12: Over-current during steady state
operation (ocn)
13: Ground fault or fuse failure(GFF)
14: Low Voltage (not record)
15: 3 Phase Input Power Loss
16: EPROM failure (CF2)
17: External interrupt allowance(bb)
18: Overload (oL2)
19: Auto Adjustable accel/decel failure
(CFA)
20: CPU self detection failure (codE)
00
Pr.76
Parameter Lock and
Configuration
00: All parameters can be set/read
01: All parameters are read-only
02-08: Reserved
09: Resets all parameters to 50Hz factory
defaults
10: Resets all parameters to 60Hz factory
defaults
00
Pr.77
Time for Auto Reset the
Restart Times in
Abnormality
0.1 to 6000.0 sec 60.0
Pr.78 PLC Operation Mode
00: Disable PLC operation
01: Execute one program cycle
02: Continuously execute program cycles
03: Execute one program cycle step by
step
04: Continuously execute one program
cycle step by step
00
Pr.79 PLC FWD/REV Motion 00 to 127 00
Pr.80
Identity Code of the AC
Motor Drive
Read only ##
Pr.81
Time Duration of 1st
Step Speed
00 to 9999 sec 00
Pr.82
Time Duration of 2nd
Step Speed
00 to 9999 sec 00
Pr.83
Time Duration of 3rd
Step Speed
00 to 9999 sec 00
