Chapter 12 Description of Parameter SettingsCP2000
12.1-13-1
13 Application Parameters by Industry
This parameter can be set during operation.
Application Selection
Default: 0
Settings 0: Disabled
1: User-defined Parameter
2: Compressor IM
3: Fan
4: Pump
10: Air Handling Unit, AHU
After you select the macro, some of the default values adjust automatically according to the
application selection.
Each setting varies with different application selection, and its value is different as well.
Refer to Section 10-2 for more operation details.
Group settings: 2: Compressor IM
The following table lists the relevant compressor application parameters.
Pr. Explanation Settings
00-11 Speed control mode 0: VF (IM V/F control)
00-16 Load selection 0: Light load
00-17 Carrier frequency Default setting
00-20
Master frequency command source (AUTO)
/ Source selection of the PID target
2: External analog input
00-21 Operation command source (AUTO) 1: External terminals.
00-22 Stop method 0: Ramp to stop
00-23 Control of motor direction 1: Disable reverse
01-00 Maximum operation frequency Default setting
01-01 Output frequency of motor 1 Default setting
01-02 Output voltage of motor 1 Default setting
01-03 Mid-point frequency 1 of motor 1 Default setting
01-04 Mid-point voltage 1 of motor 1 Default setting
01-05 Mid-point frequency 2 of motor 1 Default setting
01-06 Mid-point voltage 2 of motor 1 Default setting
01-07 Minimum output frequency of motor 1 Default setting
01-08 Minimum output voltage of motor 1 Default setting
01-11 Output frequency lower limit 20 (Hz)
01-12 Acceleration time 1 20 (s)
01-13 Deceleration time 1 20 (s)
03-00 Analog input selection (AVI1) 0: No function
03-01 Analog input selection (ACI) 1: Frequency command
05-01 Full-load current for induction motor 1(A) Default setting
