Delta VFD075CP43B-21 User Manual

Chapter 17 Introduction to BACnet │CP2000
17-5
2.3 Commandable Binary Value Object
In CP2000, we have BV_000–BV_015 supporting commandable Present_Value property. For these
BV_Objects, we also can use (Multi) Read_Service to access Priority_Array and Relinquish_Default
properties.
Object
R/W Object Name Object Description
Number
BV 000 RW ACTIVE CMD (0)FreqCmd=0;(1)FreqCmd=FreqRefValue
BV 001 RW FWD/REV CMD (0)Forward; (1)Reverse
BV 002 RW Reserved Reserved
BV 003 RW HALT CMD (0)None;(1)Ramp Down to 0 Hz.
BV 004 RW LOCK CMD (0)None;(1)OutputFreq stays at current frequency
BV 005 RW Reserved Reserved
BV 006 RW QSTOP CMD (0)None;(1)Force driver quick stop
BV 007 RW ServoPower CMD (0)PowerOff(free run to stop);(1)PowerOn
BV 008 RW Reserved Reserved
BV 009 RW Reserved Reserved
BV 010 RW Reserved Reserved
BV 011 RW Reserved Reserved
BV 012 RW Reserved Reserved
BV 013 RW Reserved Reserved
BV 014 RW Reserved Reserved
BV 015 RW RESET RESET:(0)Do nothing;(1)Reset fault
2.4 Status (Readonly) Binary Value Object
In CP2000, we have BV_016–BV_031 with read-only Present_Value property. For these BV_Objects,
we do NOT have Priority_Array and Relinquish_Default properties.
Object
R/W Object Name Object Description
Number
BV 016 R ARRIVE STATE (0)Not yet;(1)Arrive (OutputFreq=FreqCmd)
BV 017 R FWD/REV STATE (0)Forward;(1)Reverse
BV 018 R WARN STATE (0)No Warn;(1)Occur Warn
BV 019 R ERROR STATE (0)No Error;(1)Occur Error
BV 020 R Reserved Reserved
BV 021 R Reserved Reserved
BV 022 R QSTOP STATE (0)No QSTOP;(1)Occur QSTOP
BV 023 R Servo Power STATE (0)PowerOff(free run to stop);(1)PowerOn
BV 024 R Reserved Reserved
BV 025 R Reserved Reserved
BV 026 R Reserved Reserved
BV 027 R Reserved Reserved
BV 028 R Reserved Reserved
