Delta VFD1100C43A-HS

Chapter 11 Summary of Parameter SettingsC2000-HS
11-14
Pr. Parameter Name Setting Range Default
36: Error output selection 2 (Pr. 06-24)
37: Error output selection 3 (Pr. 06-25)
38: Error output selection 4 (Pr. 06-26)
39: Position reached (Pr. 10-19)
40: Speed reached (including stop)
41: Multi-position reached
42: Crane function
43: Actual motor speed higher than Pr. 02-47
44: Low current output (use with Pr. 06-71–06-73)
45: UVW output electromagnetic valve switch
46: Master dEb output
47: Closed brake output
49: Homing action complete output
50: Output control for CANopen
51: Analog output control for RS-485 interface
(InnerCOM / MODBUS)
52: Output control for communication cards
65: Output for both CANopen & RS-485 control
66: SO output logic A
67: Analog input level reached
68: SO output logic B
70: FAN warning detection output

02-18 Multi-function output direction 0000h–FFFFh (0: N.O.; 1: N.C.) 0000h

02-19
Terminal counting value reached
(returns to 0)
0–65500 0

02-20
Preliminary counting value reached
(does not return to 0)
0–65500 0

02-21 Digital output gain (DFM) 1–166 1

02-22 Desired frequency reached 1 0.0–1500.0 Hz 600.0

02-23
The width of the desired frequency
reached 1
0.0–1500.0 Hz 2.0

02-24 Desired frequency reached 2 0.0–1500.0 Hz 600.0

02-25
The width of the desired frequency
reached 2
0.0–1500.0 Hz 2.0
02-32 Brake delay time 0.000–65.000 sec. 0.000

02-33
Output current level setting for
multi-function output terminal
0–100% 0

02-34
Output frequency setting for
multi-function output terminal
0.0–1500.0 Hz
(Motor speed when using PG Card)
3.0
