Chapter 12 Description of Parameter SettingsC2000-HS
12.1-02-14
44: Low current output (use with Pr. 06-71–Pr. 06-73)
45: UVW output electromagnetic valve switch
46: Master dEb output
47: Closed brake output
49: Homing action complete output
50: Output control for CANopen
51: Analog output control for RS-485 interface (InnerCOM / MODBUS)
52: Output control for communication cards
65: Output for both CANopen and RS-485 control
66: SO output logic A
67: Analog input level reached
68: SO output logic B
70: FAN warning detection output
Use this parameter to set the function of the multi-function terminals.
Pr. 02-36–Pr. 02-41 requires additional extension cards to display the parameters, the choices of
optional cards are EMC-D42A and EMC-R6AA.
The optional card EMC-D42A provides two output terminals, use with Pr. 02-36–Pr. 02-37.
The optional card EMC-R6AA provides six output terminals, use with Pr. 02-36–Pr. 02-41.
Summary of function settings
Take the normally open contact (N.O.) for example, ON: contact is closed, OFF: contact is open
Settings Functions Descriptions
0 No Function
1 Indication during RUN Active when the drive is not in STOP.
2
Operation speed
reached
Active when output frequency of the drive reaches the setting
frequency.
3
Desired frequency
reached 1 (Pr. 02-22)
Active when the desired frequency (Pr. 02-22) reached.
4
Desired frequency
reached 2 (Pr. 02-24)
Active when the desired frequency (Pr. 02-24) reached.
5
Zero speed (frequency
command)
Active when frequency command =0 (the drive must be in RUN
status.)
6
Zero Speed, includes
STOP (frequency
command)
Active when frequency command =0 or stopped.
7 Over-torque 1
Active when the drive detects over-torque. Pr. 06-07 sets the
over-torque detection level, and Pr. 06-08 sets the over-torque
detection time. Refer to Pr. 06-06–Pr. 06-08.
8 Over-torque 2
Active when the drive detects over-torque. Pr. 06-10 sets the
over-torque detection level, and Pr. 06-11 sets the over-torque
detection time. Refer to Pr. 06-09–Pr. 06-11.
