Chapter 3 UnpackingC2000-HS
3-6
Frame F
Remove the six buckles fixed on the crate with a flat-head screwdriver, see the figure below.
1
2
3
6
5
4
Remove the top cover, take out the EPEs and the manual.
Loosen the five screws fasten the drive on the pallet, see the figure below.
1
2
3
4
5
Figure 3-8
Figure 3-9
Figure 3-10
