Chapter 12 Description of Parameter SettingsC2000-HS
12.1-13-3
Group setting 04: Pump
The following table lists the relevant pump setting application parameters.
Pr. Explanation Settings
00-11 Speed control mode 0 (V/F control)
00-16 Load Selection 0 (Normal load)
00-20
Master frequency command source (AUTO)
/ Source selection of the PID target
2 (External analog input)
00-21 Operation command source (AUTO) 1 (External terminals)
00-23 Control of motor direction 1 (Disable reverse)
01-00 Maximum operation frequency Default setting
01-01 Output frequency of motor 1 Default setting
01-02 Output voltage of motor 1 Default setting
01-03 Mid-point frequency 1 of motor 1 Default setting
01-04 Mid-point voltage 1 of motor 1 Default setting
01-05 Mid-point frequency 2 of motor 1 Default setting
01-06 Mid-point voltage 2 of motor 1 Default setting
01-07 Minimum output frequency of motor 1 Default setting
01-08 Minimum output voltage of motor 1 Default setting
01-10 Output frequency upper limit 50 (Hz)
01-11 Output frequency lower limit 35 (Hz)
01-12 Acceleration time 1 15 (s)
01-13 Deceleration time 1 15 (s)
01-43 V/F curve selection 2 (Second V/F curve)
07-06 Restart after momentary power loss
2 (Speed tracking by minimum output
frequency)
07-11 Number of times of restart after fault 5
07-33 Auto-restart interval of fault 60 (s)
