Delta VFD110ED43S User Manual

Chapter 11 Summary of Parameter Settings | VFD-ED
11-10
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
 02-19
Multi-function Output 9:
(MO5)
10: User-defined low-voltage detection
(LV)
0 ○ ○ ○ ○ ○
 02-20
Multi-function Output
10: (MO6)
11: Malfunction indication 0 ○ ○ ○ ○ ○
12: Mechanical brake release (Pr.02-
29,
Pr.02-30, Pr.02-37)
0 ○ ○ ○ ○ ○
13: Overheat (Pr.06-14)
0
○
○
○
○
○
14: Brake transistor signal
○
○
○
○
○
15: Motor-controlled magnetic contactor
output
○ ○ ○ ○ ○
16: Slip error (oSL)
○
○
○
○
○
17: Malfunction indication 1
○
○
○
○
○
18: Reserved
19: Brake transistor output error
○
○
○
○
○
20: Warning output
○
○
○
○
○
21: Over-voltage warning
○
○
○
○
○
22: Over-current stall prevention
warning
○ ○ ○
23: Over-voltage stall prevention
warning
○ ○ ○ ○ ○
24: Operation mode indication (Pr.00-
15=1)
○ ○ ○ ○ ○
25: Forward command
○
○
○
○
○
26: Reverse command
○
○
○
○
○
27: Output when current ≥ Pr.02-33
○
○
○
○
○
28: Output when current < Pr.02-33
○
○
○
○
○
29: Output when frequency ≥ Pr.02-34
○
○
○
○
○
30: Output when frequency < Pr.02-34
○
○
○
○
○
31: Power generation direction and
status verification
○ ○ ○ ○ ○
32: Power generation direction
○
○
○
○
○
33: Zero speed (actual output
frequency)
○ ○ ○ ○ ○
34: Zero speed with Stop (actual output
frequency)
○ ○ ○ ○ ○
35: Fault output option 1 (Pr.06-22)
○
○
○
○
○
36: Fault output option 2 (Pr.06-23)
○
○
○
○
○
37: Fault output option 3 (Pr.06-24)
○
○
○
○
○
38: Fault output option 4 (Pr.06-25)
○
○
○
○
○
39: Reserved
40: Speed reached (including zero
speed)
○ ○ ○ ○ ○
41: Reserved
42: STO output error
○
○
○
○
○
43–44: Direct docking mode only
◆
