Chapter 16 PLC Function Applications│CP2000
16-54
Classification API
Command code
P
command
Function
STEPS
16 bit 32 bit 16bit 32bit
133
–
DASIN

Binary floating point number
ASIN operation
– 9
134
–
DACOS

Binary floating point number
ACOS operation
– 9
135
–
DATAN

Binary floating point number
ATAN operation
– 9
Floating point
operation
136
–
DSINH

Binary floating point number
SINH operation
– 9
137
–
DCOSH

Binary floating point number
COSH operation
– 9
138
–
DTANH

Binary floating point number
TANH operation
– 9
Other 147 SWAP DSWAP

Exchange the up/down 8 bits 3 5
Communication 150 MODRW –

Modbus read/write 7 –
Calendar
160 TCMP –

Compare calendar data 11 –
161 TZCP –

Compare calendar data range 9 –
162 TADD –

Calendar data addition 7 –
163 TSUB –

Calendar data subtraction 7 –
166 TRD –

Calendar data read 3 –
GRAY code
170 GRY DGRY

BIN→GRY code
transformation
5 9
171 GBIN DGBIN

GRY code →BIN
transformation
5 9
Contact form
logical operation
215 LD& DLD& –
Contact form logical operation
LD#
5 9
216 LD| DLD| –
Contact form logical operation
LD#
5 9
217 LD^ DLD^ –
Contact form logical operation
LD#
5 9
218 AND& DAND& –
Contact form logical operation
AND#
5 9
219 ANDl DANDl –
Contact form logical operation
AND#
5 9
220 AND^ DAND^ –
Contact form logical operation
AND#
5 9
221 OR& DOR& –
Contact form logical operation
OR#
5 9
222 OR| DOR| –
Contact form logical operation
OR#
5 9
223 OR^ DOR^ –
Contact form logical operation
OR#
5 9
Contact form
compare
command
224
LD＝ DLD＝
– Contact form compare LD
※ 5 9
225
LD＞ DLD＞
– Contact form compare LD※ 5 9
226
LD＜ DLD＜
– Contact form compare LD※ 5 9
228
LD＜＞ DLD＜＞
– Contact form compare LD※ 5 9
229
LD＜＝ DLD＜＝
–
Contact form compare LD
※
5 9
230
LD＞＝ DLD＞＝
–
Contact form compare LD
※
5 9
232
AND＝ DAND＝
–
Contact form compare AND
※
5 9
233
AND＞ DAND＞
–
Contact form compare AND
※
5 9
234
AND＜ DAND＜
–
Contact form compare AND
※
5 9
236
AND＜＞ DAND＜＞
–
Contact form compare AND
※
5 9
237
AND＜＝ DAND＜＝
–
Contact form compare AND
※
5 9
238
AND＞＝ DAND＞＝
–
Contact form compare AND
※
5 9
240
OR＝ DOR＝
–
Contact form compare OR
※
5 9
241
OR＞ DOR＞
–
Contact form compare OR
※
5 9
242
OR＜ DOR＜
–
Contact form compare OR
※
5 9
244
OR＜＞ DOR＜＞
–
Contact form compare OR
※
5 9
245
OR＜＝ DOR＜＝
–
Contact form compare OR
※
5 9
246
OR＞＝ DOR＞＝
–
Contact form compare OR
※
5 9
