Chapter 1 IntroductionCP2000
1-19
Frame G
G1: VFD2200CP43A-00; VFD2800CP43A-00; VFD2500CP63A-00; VFD3150CP63A-00
W1
W
H2
H1
H3
D
S3
See Detail A
See Detail B
Detail A
(Mounting Hole)
Detail B
(Mounting Hole)
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 S1 S2 S3 Φ1 Φ2 Φ3
G1
500.0
[19.69]
-
397.0
[15.63]
440.0
[217.32]
1000.0
[39.37]
963.0
[37.91]
913.6
[35.97]
13.0
[0.51]
26.5
[1.04]
27.0
[1.06]
- - -
See Detail
A
See Detail B
Detail A
(Mounting Hole)
Detail B
(Mounting Hole)
