Delta VFD150CP43B-21 User Manual

Chapter 1 IntroductionCP2000
1-20
Frame G
G2: VFD2200CP43A-21; VFD2800CP43A-21; VFD2500CP63A-21; VFD3150CP63A-21
W1
S3
D
H3
H
H1
H2
W
Figure 1-26
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 S1 S2 S3 Φ1 Φ2 Φ3
G2
500.0
[19.69]
1240.2
[48.83]
397.0
[15.63]
440.0
[217.32]
1000.0
[39.37]
963.0
[37.91]
913.6
[35.97]
13.0
[0.51]
26.5
[1.04]
27.0
[1.06]
22.0
[0.87]
34.0
[1.34]
117.5
[4.63]
See Detail
A
See Detail B
Detail A
(Mounting Hole)
Detail B
(Mounting Hole)

Delta VFD150CP43B-21 Specifications

General

Brand	Delta
Model	VFD150CP43B-21
Category	DC Drives
Language	English
