Chapter 12 Description of Parameter SettingsCP2000
12.1-06-14
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
53: Software code error ●
54: Communication error (CE1) ●
55: Communication error (CE2) ●
56: Communication error (CE3) ●
57: Communication error (CE4) ●
58: Communication Time-out (CE10) ●
60: Brake transistor error (bF) ●
61: Y-connection/∆-connection switch error (ydc) ●
62: Deceleration Energy Backup Error (dEb) ●
63: Slip error (oSL) ●
64: Electromagnet switch error (ryF) ●
72: Channel 1 (STO1–SCM1) safety loop error
(STL1)
●
73: External safety gate S1 ●
74: FIRE mode output ●
76: Safety Torque Off (STO) ●
77: Channel 2 (STO2–SCM2) safety loop error
(STL2)
●
78: Internal loop error (STL3) ●
79: U-phase output short-circuit (Uoc) ●
80: V-phase output short-circuit (Voc) ●
81: W-phase output short-circuit (Woc) ●
82: U-phase output phase loss (OPHL) ●
83: V-phase output phase loss (OPHL) ●
84: W-phase output phase loss (OPHL) ●
90: Inner PLC function is forced to stop ●
99: TRAP CPU command error ●
101: CANopen software disconnect 1 (CGdE) ●
102: CANopen software disconnect 2 (CHbE) ●
103: CANopen synchronous error (CSyE) ●
104: CANopen hardware disconnect (CbFE) ●
105: CANopen index setting error (CIdE) ●
106: CANopen slave station number setting error
(CAdE)
●
107: CANopen index setting exceed limit (CFrE) ●
111: Internal communication overtime error (ictE) ●
PTC Detection Selection / PT100 Motion
Default: 0
Settings 0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: No warning
Sets the operation mode of a drive after you set Pr.06-29 to define PTC / PT100 / KTY84
detection.
