Chapter 12 Description of Parameter SettingsCP2000
12.1-06-15
PTC Level
Default: 50.0
Settings 0.0–100.0%
Sets AVI1/ACI/AVI2 analog input function Pr.03-00–03-02 to 6 [Positive Temperature Coefficient
(P.T.C.) thermistor input value].
Use this to set the PTC level, the corresponding value for 100% is the analog input maximum
value.
Frequency Command for Malfunction
Default: Read only
Settings 0.00–599.00 Hz
When a malfunction occurs, check the current frequency command. If it happens again, it
overwrites the previous record.
Output Frequency at Malfunction
Default: Read only
Settings 0.00–599.00 Hz
When a malfunction occurs, check the current output frequency. If it happens again, it overwrites
the previous record.
Output Voltage at Malfunction
Default: Read only
Settings 0.0–6553.5 V
When a malfunction occurs, check the current output voltage. If it happens again, it overwrites the
previous record.
DC Voltage at Malfunction
Default: Read only
Settings 0.0–6553.5 V
When a malfunction occurs, check the current DC voltage. If it happens again, it overwrites the
previous record.
Output Current at Malfunction
Default: Read only
Settings 0.0–6553.5 Amp
When a malfunction occurs, check the current output current. If it happens again, it overwrites the
previous record.
IGBT Temperature at Malfunction
Default: Read only
Settings -3276.7–3276.7°C
When a malfunction occurs, check the current IGBT temperature. If it happens again, it
overwrites the previous record.
