Chapter 2 Wiring | VFD-VJ
2-14
short-circuit object before connecting to the DC reactor.
+1
Jumper
DC reactor
For those models without built-in brake resistor, please connect external brake
unit and brake resistor (both of them are optional) to increase brake torque.
DO NOT connect [B2] or [-] to [+2/B1] directly to prevent drive damage.
