Delta VFD1A5MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
207
Pr.
Explanation
Settings
Default
482: 460 V, 3 Phase, 4 HP
504: 575 V, 3 Phase, 1 HP
505: 575 V, 3 Phase, 2 HP
506: 575 V, 3 Phase, 3 HP
507: 575 V, 3 Phase, 5 HP
508: 575 V, 3 Phase, 7.5 HP
509: 575 V, 3 Phase, 10 HP
00-01
AC Motor Drive Rated
Current Display
Display by models
Read only
00-02
Parameter Reset
0: No function
1: Write protection for parameters
5: Return kWh displays to 0
6: Reset PLC (including CANopen Master Index)
7: Reset CANopen Slave index
8: Keypad does not respond
9: Reset all parameters to defaults
(base frequency is 50 Hz)
10: Reset all parameters to defaults
(base frequency is 60 Hz)
11: Reset all parameters to defaults with base frequency
at 50 Hz (keep the user-defined parameter values
Pr.13-01–Pr.13-50)
12: Reset all parameters to defaults with base frequency
at 60 Hz (keep the user-defined parameter values
Pr.13-01–Pr.13-50)
0

00-03
Start-Up Display
0: F (frequency command)
1: H (output frequency)
2: U (user-defined, see Pr.00-04)
3: A (output current)
0

00-04
Content of Multi-Function
Display (User-Defined)
0: Display output current (A) (unit: Amp)
1: Display counter value (c) (unit: CNT)
2: Display the drive’s actual output frequency (H.)
(unit: Hz)
3: Display the drive’s DC bus voltage (V) (unit: V
DC
)
4: Display the drive’s output voltage (E) (unit: V
AC
)
5: Display the drive’s output power angle (n) (unit: deg)
6: Display the drive’s output power (P) (unit: kW)
7: Display the motor speed rpm (r) (unit: rpm)
8: Display the drive’s estimated output torque, motor’s
rated torque is 100% (t) (unit: %)
3
