Delta VFD1A5MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
208
Pr.
Explanation
Settings
Default
10: Display PID feedback (b) (unit: %)
11: Display AVI analog input terminal signal (1.) (unit: %)
12: Display ACI analog input terminal signal (2.) (unit: %)
14: Display the drive’s IGBT temperature (i.) (unit:
o
C)
16: The digital input status (ON / OFF) (i)
17: The digital output status (ON / OFF) (o)
18: Display multi-step speed (S)
19: The corresponding CPU digital input pin status (d)
20: The corresponding CPU digital output pin status (0.)
22: Pulse input frequency (S.)
25: Overload count (0.00–100.00%) (o.) (unit: %)
26: Ground fault GFF (G.) (unit: %)
27: DC bus voltage ripple (r.) (unit: V
DC
)
28: Display PLC register D1043 data (C)
30: Display the output of User-defined (U)
31: Display Pr.00-05 user gain (K)
35: Control mode display:
0 = Speed control mode (SPD)
1 = Torque control mode (TQR) (t.)
36: Present operating carrier frequency of the drive (J.)
(Unit: Hz)
38: Display the drive status (6.)
39: Display the drive’s estimated output torque, positive
and negative, using Nt-m as unit
(t 0.0: positive torque; -0.0: negative torque) (C.)
40: Torque command (L.) (unit: %)
41: kWh display (J) (unit: kWh)
42: PID target value (h.) (unit: %)
43: PID compensation (o.) (unit: %)
44: PID output frequency (b.) (unit: Hz)
46: Auxiliary frequency value (U.) (unit: Hz)
47: Master frequency value (A) (unit: Hz)
48: Frequency value after addition and subtraction of
master and auxiliary frequency (L.) (unit: Hz)
51: PMSVC torque offset
58: Pr.00-05 User gain display (K)
(Does not display decimal places.)
62: I2t (o.) (unit: %)
63: Error code (E.)
64: Warning code (n.)
