Delta VFD1A5MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
226
Pr.
Explanation
Settings
Default

03-31
AFM Output Selection
0: 0–10 V output
1: 0–20 mA output
2: 4–20 mA output
0

03-32
AFM DC Output Setting
Level
0.00–100.00%
0.00

03-35
AFM Output Filter Time
0.00–20.00 sec.
0.01

03-39
VR Input Selection
0: Disable
1: Frequency command
1

03-40
VR Input Bias
-100.0–100.0%
0.0

03-41
VR Positive / Negative
Bias
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving as
the center
4: Bias serves as the center
0

03-42
VR Gain
-500.0–500.0%
100.0

03-43
VR Filter Time
0.00–2.00 sec.
0.01

03-44
Multi-Function Output
(MO) by AI Level Source
0: AVI
1: ACI
0

03-45
AI Upper Level
-100–100%
50

03-46
AI Lower Level
-100–100%
10

03-50
Analog Input Curve
Selection
0: Normal curve
1: Three-point curve of AVI
2: Three-point curve of ACI
3: Three-point curve of AVI & ACI
0

03-57
ACI Lowest Point
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA
4.00

03-58
ACI Proportional Lowest
Point
0.00–100.00%
0.00

03-59
ACI Mid-Point
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA
12.00

03-60
ACI Proportional Mid-
Point
0.00–100.00%
50.00

03-61
ACI Highest Point
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA
20.00

03-62
ACI Proportional Highest
Point
0.00–100.00%
100.00

03-63
AVI Voltage Lowest Point
0.00–10.00 V
0.00

03-64
AVI Proportional Lowest
Point
-100.00–100.00%
0.00
