Chapter 11 Summary of Parameter SettingsMS300
227
Pr.
Explanation
Settings
Default

03-65
AVI Voltage Mid-Point
0.00–10.00 V
5.00

03-66
AVI Proportional Mid-
Point
-100.00–100.00%
50.00

03-67
AVI Voltage Highest Point
0.00–10.00 V
10.00

03-68
AVI Proportional Highest
Point
-100.00–100.00%
100.00

03-69
Negative AVI Voltage
Lowest Point
-10.00–0.00 V
(valid when Pr.03-28 sets as -10–10 V)
0.00

03-70
Negative AVI Proportional
Lowest Point
-100.00–100.00%
(valid when Pr.03-28 sets as -10–10 V)
0.00

03-71
Negative AVI Voltage
Mid-Point
-10.00–0.00 V
(valid when Pr.03-28 sets as -10–10 V)
-5.00

03-72
Negative AVI Proportional
Mid-Point
-100.00–100.00%
(valid when Pr.03-28 sets as -10–10 V)
-50.00

03-73
Negative AVI Voltage
Highest Point
-10.00–0.00 V
(valid when Pr.03-28 sets as -10–10 V)
-10.00

03-74
Negative AVI Proportional
Highest Point
-100.00–100.00%
(valid when Pr.03-28 sets as -10–10 V)
-100.00
